| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Marine Turbo |
| Certification: | ISO; CCS; GL |
| Model Number: | AT14 |
| Minimum Order Quantity: | 1 pcs |
| Packaging Details: | Carton box, wood case |
| Delivery Time: | 2-3 working days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 300 pcs / month |
| Model: | AT14 | Product Name: | IHI Turbocharger, Exhaust Gas Turbocharger, TC Complete |
|---|---|---|---|
| Engine Type: | Diesel Engine And Heavy Duty Fuel Oil Engines | Engine Power Range: | 320 -750 KW |
| Cooling Method: | Water Cooled | Warranty: | 12 Months |
| Application: | Automotive, Heavy Truck, Construction, Marine And Industrial Engine | ||
| High Light: | 500KW Engine Marine Turbocharger,Water Cooled Marine Turbocharger,IHI AT14 Marine Engine Turbocharger |
||
IHI / AT14 turbocharger has the design features as following.
| T- RH Series | T- AT Series | T- RU Series | |
| T- IHI | T- RH133 | T- AT14 | T- RU110 |
| T- RH143 | T- RU120 | ||
| T- RH163 | |||
| T- RH183 | |||
| T- RH203 |
The above T- AT14 Turbocharger's cross-sectional drawing shows that the T- AT14 turbocharger is consisted of the turbine and compressor, and the thrust bearing and two journal bearings which make the axial and radial forces respectively becoming possible. From static section view, T-AT14 turbocharger consists of the comprssor casing, bearing casing and turbine casing.
Dimensions:
| Description |
Dimension (mm) |
| rotor length | 300 |
| diameter of turbine inlet | 140 |
| diameter for compressor outlet | 140 |
The marine turbocharger, also known as exhaust gas turbocharger, is the main equipment in the diesel engine boosting system. It consists of a single-stage exhaust gas turbine and a centrifugal compressor. They are mounted on the same shaft to form the moving part of the marine turbocharger/exhaust gas turbocharger - the rotor. The function of the marine turbocharger/exhaust gas turbocharger is to use the diesel exhaust energy to drive the turbine to drive the compressor on the coaxial to increase the air pressure into the cylinder, so that the diesel engine power is greatly improved.
Marine Turbo is dedicated to manufacture and sell the marine turbocharger spare parts and components with reliable quality and service including cartridge, rotor complete, bearings, diffuser, nozzle ring, cover ring, oil pump, sealing bush, turbo housings, service kit, tools, etc.
