| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Marine Turbo |
| Certification: | ISO; CCS; GL |
| Model Number: | T-NA series |
| Minimum Order Quantity: | 1 pcs |
| Packaging Details: | Carton box, wood case |
| Delivery Time: | 1-4 working days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 500 pcs / month |
| Model: | T-NA SERIES Sealing Bush | Product Name: | Turbocharger Nozzle Ring, Marine Turbocharger Nozzle Ring, Marine Turbo Nozzle Ring |
|---|---|---|---|
| Size: | Standard Size, Or As Customer's Request | Type 3: | T-MAN T-NA Turbocharger |
| Fuel: | Heavy Fuel Oil, Marine Diesel Oil, Biofuel And Gas Operation | Engine Power Range: | 1650 KW -24,500kW |
| Bearing Design: | Inboard Plain Bearing Design | Warranty: | 12 Months |
| High Light: | turbo seal,turbo oil seal |
||
| T-MAN | T-NA Series |
| T-NA34/T | |
| T-NA34/S | |
| T-NA40/T | |
| T-NA40/S | |
| T-NA48/T | |
| T-NA48/S | |
| T-NA57/N | |
| T-NA57/M | |
| T-NA57/T7 | |
| T-NA57/T8 | |
| T-NA57/T9 | |
| T-NA70/T7 | |
| T-NA70/T9 |
The function of turbocharger diffuser:
The turbine is driven by the engine exhaust gas, which enters via the gas inlet casing. The gas expands through a nozzle ring where the pressure energy of the gas is converted to kinetic energy. This high velocity gas is directed onto the turbine blades where it drives the turbine wheel, and thus the compressor at high speeds (10 -15000 rpm). The exhaust gas then passes through the outlet casing to the exhaust uptakes.
The nozzle ring need to bear the extremely high temperature and high pressure, so it's very crucial for its material selection.
The turbocharger nozzle ring is usually fabricated from a creep resistant chromium nickel alloy, heat resisting moly-chrome nickel steel or a nimonic alloy.
T-MAN/T-NA series supercharger is a axial-flow turbocharger. T-NA turbochargers adopts inboard plain bearing, uncooled casings and lubricated by the engine's lube oil system.
The function of turbocharger nozzle ring:
Brief introduction of Marine turbocharger:
When the diesel-exhaust turbocharger combination is in operation, the marine turbocharger/exhaust gas turbocharger is prone to failures such as turbine casing corrosion, bearing damage, blade damage, gas seal damage, and supercharger vibration. The daily good maintenance management can reduce these failures.
Marine Turbo has been specialized in turbocharger spare parts replacement for Marine, drilling and Mining industry for more than 20 years since 1999, serving hundreds and thousands customers from the whole world with premium quality product and quick service on offering and delivery. Marine Turbo has more than 100 models for customers to choose quickly which suitable for T-MAN, T-ABB, T-KBB, T-MET, T-IHI and other brands of turbocharger spare parts replacement. Among them, 90% of the product model Marine Turbo has inventory, can meet the turbocharger maintenance, repair or overhaul needs for various brands with a quick response and a reasonable price.
Marine Turbo also can provide product customization services to meet the personalized needs of customers. According to the sample or drawings provided by customers, Marine Turbo can process and manufacture the corresponding products in order to provide customers with sound-quality products at low cost.
With over 20 years of manufacturing experience, Marine Turbo supply a wide range of marine turbocharger spare parts replacements in marine, drilling and mining industry: marine turbocharger complete, compressor wheel / impeller, turbine shaft, cartridge, rotor complete, bearing assembly, nozzle ring, diffuser, cover ring, oil pump, sealing bush, compressor housing, bearing housing, turbine casing, silencer, service kits, tools, etc....
| T-ABB | T-VTR“0”“1”“4”, P/D/E | |||||
| T-TPS44D/E/F | T-TPS48D/E/F | T-TPS52D/E/F | T-TPS57D/E/F | T-TPS61D/E/F | ||
| T-TPL65 | T-TPL69 | T-TPL73 | T-TPL77 | T-TPL80 | T-TPL85 | |
| T-RR151 | T-RR181 | |||||
| T-A145-M | T-A170 | |||||
| T-MAN | T-NR12/S | T-NR15/R | T-NR17/S | T-NR20 | T-NR20/R | T-NR20/S |
| T-NR24/R | T-NR24/S | T-NR26/R | T-NR29/S | T-NR34/S | ||
| T-NA34T/34S | TNA40T/40S | T-NA48T/48S | T-NA57T/57T9 | T-NA70T/70T9 | ||
| T-TCR12 | T-TCR16 | T-TCR18 | T-TCR20 | T-TCR22 | ||
| T-TCA44 | T-TCA55 | T-TCA66 | T-TCA77 | T-TCA88 | ||
| T-MET | T-MET18SRC | T-MET26SR | T-MET30SR | |||
| T-MET33SB/SBII/SC/SD | T-MET35/35S/35SA/350 | T-MET42SB/SBII/SC/SD/SE | T-MET45/45S/450 | T-MET53SB/SBII/SC/SD/SE | ||
| T-MET66SB/SC/SD | 56S-B | 560 | 60MA | 66SB/SC/SD/SE/SEII | ||
| T-MET53SE | ||||||
| T-MET83SE | T-MET83SEII | |||||
| T-KBB | T-HPR3000 | T-HPR4000 | T-HPR5000 | T-HPR6000 | ||
| ST5 SERIES | ||||||
| T-HRBR3-2 | T-HRBR4-3 | |||||
| T-IHI | T-RH133 | T-RH143 | T-RH163 | T-RH183 | T-RH203 | |
| T-AT14 | ||||||
| T-RU110 | T-RU120 |
Marine Turbo also can supply some types of T/C Complete, sucah as T-RH133/163, T-AT14, T-TCR12, T-TD08H, etc.
Currently, Marine Turbo has stock for original new turbocharger complete: T-RH143 1 pc, T-RH163 1 pc , T-RH183 1pc; and also has the stock for secondary-hand turbocharger complete: T-VTR714D 3 pcs；T-NA57T7 2 pcs,T-NA48/S 1 pc,T-NA48/T 2 pcs,T-MET66SD 1 pc.
Marine Turbo's turbocharger replacement parts help to power all types of ships, large and small, including container ships, tankers, cargo vessels, cruise ships, tugboats, etc., and also drilling diesel engine, mining machinery with diesel engine.
All Marine Turbo products must pass all of our strict Quality Assurance procedures and standards, both on receipt from our suppliers, and before dispatch to our many and valued customers. All units are supplied with a full test report and balance report.
Marine Turbo factory has passed the ISO9000 Quality Management System certificate in 2001, and most of turbocharger replacement parts are certificated by CCS and GL.
Marine Turbo remains at your full disposal for any further inquiries or questions.
